Automatic Horizontal Cartoning Machine for Bottle Box Carton Box Packing Machine

Multi-functional Automatic Cartoning Machine is the latest model which is developed by our company through the combination of advanced technology both at home and abroad.It is one high-tech product that integrates the light,electric,air and motor which greatly enhance the equipment characteristic and working efficiency.It can meet the requirements of quick packing easily and maintain a steady and reliable state while the machine is under fast running circumstances.

This machine is mainly suitable for the automatic product packing of pharmaceutical,food,health care products,batteries,hardware and other industries .It mainly completes a series of processes,such as conveying the packed products,automatic unwrapping of carton,automatic packing for user guide(optional) and products,transportation of packed finished products and automatic removal of waste products etc.,and finally realizes automatic packing of products.

Packing Speed		20-100 boxes/min(Products related)
Paper/Carton Box	Specification	250-350g/m²( According to the size of box)
	Range of Box Size	(55-300)×(30-170)×(15-50)mm
Instructions	Specification	55-65g/m²
	Unfolded Size Range	(100-250)×(100-190)mm
	Folded Range	1-4 Fold
Compressed Air	Working Pressure	0.5-0.7Mpa
	Air Consumption	0.2m³/min
Total Power		380V/220V 50Hz 1.5Kw
Main Motor Power		1.5kw
Overall Dimension		4100×1350×1450mm
Weight		1800kg

1.The cover of this machine is made of 304 stainless steel and equipped with aluminum alloy openable tempered glass protective door, which is safe and convenient enough for operator.

2.This machine adopts PLC and photoelectric tracking system to monitor the packaging process.When the machine runs out of cartons or paper jams,it will alert the operator for the error.When this kind of problem occurs, the machine will issue an alarm to remind the operator.

3.The machine is equipped with automatic feeding, box opening, product into box, box sealing, waste removal and other functions.

4.Customers can make personalized feeder according to the product or choose to connect the machine with the previous relevant equipment.The following process can be equipped with three - dimensional packaging machine and inspection weighing scale.

5.The machine adopts man-machine interface, easy to adjust each step of operation.The machine is equipped with same level monitoring function, any error can be displayed and alarm.
