NF-120
KXITE
Automatic plastic/lami tube filling and sealing machine is a new filling equipment which is independently developed and designed and manufactured by our company, based on foreign advanced filling and sealing machine type and combined with the domestic actual circumstances of plastic/lami tube.The machine type is wholly closed in stainless steel, suitable to filling and sealing of various specifications plastic/lami tube, max speed reaches120 tubes per minute, actual normal speed reaches 80 to 120 tubes per minute, variable speed via frequency converter. Filling precision is equal to or less than 0.5%. The sealing manner for plastic/lami tubes is hot air sealing.
Features and innovation:
1.NF-120 plastic/lami tube filling and sealing machine is a full automatic double stations type. Adopting advanced Norden drive technology and combining domestic actual circumstances, the unique main drive system is designed, Cam is a forged steel part which assures durability.
2.The machine provides secure and stable production at high speeds via frequency converter to modulate the velocity, so making filling more precise.
3.No tube no filling.
4.Automatic adjustable device for load capacity.
5.Protective device
Product Parameters
| Model | Automatic High Speed Tube Filling And Sealing Machine |
| Product capacity | 80-120 pcs/min |
| Filling Range | 3-250 ml |
| Filling accuracy | ≤±1% |
| Suitable Tube Length | 50-250 mm |
| Suitable Tube Diamete | 13-50mm |
| Tube material | Plastics tubes,compound tubes and metal tubes |
| Power Supply | 50Hz/380V 3P |
| Main Motor | 2.2KW |
| Working Pressure | 0.5-0.6MPa |
| Control Mode | PLC+Touch Screen (SIEMENS) |
| Whole Machine | 2350×1300×2400 mm |
| Weight | (About) 1400 Kg |
Automatic plastic/lami tube filling and sealing machine is a new filling equipment which is independently developed and designed and manufactured by our company, based on foreign advanced filling and sealing machine type and combined with the domestic actual circumstances of plastic/lami tube.The machine type is wholly closed in stainless steel, suitable to filling and sealing of various specifications plastic/lami tube, max speed reaches120 tubes per minute, actual normal speed reaches 80 to 120 tubes per minute, variable speed via frequency converter. Filling precision is equal to or less than 0.5%. The sealing manner for plastic/lami tubes is hot air sealing.
Features and innovation:
1.NF-120 plastic/lami tube filling and sealing machine is a full automatic double stations type. Adopting advanced Norden drive technology and combining domestic actual circumstances, the unique main drive system is designed, Cam is a forged steel part which assures durability.
2.The machine provides secure and stable production at high speeds via frequency converter to modulate the velocity, so making filling more precise.
3.No tube no filling.
4.Automatic adjustable device for load capacity.
5.Protective device
Product Parameters
| Model | Automatic High Speed Tube Filling And Sealing Machine |
| Product capacity | 80-120 pcs/min |
| Filling Range | 3-250 ml |
| Filling accuracy | ≤±1% |
| Suitable Tube Length | 50-250 mm |
| Suitable Tube Diamete | 13-50mm |
| Tube material | Plastics tubes,compound tubes and metal tubes |
| Power Supply | 50Hz/380V 3P |
| Main Motor | 2.2KW |
| Working Pressure | 0.5-0.6MPa |
| Control Mode | PLC+Touch Screen (SIEMENS) |
| Whole Machine | 2350×1300×2400 mm |
| Weight | (About) 1400 Kg |
