DZP-260
KXITE
It is widely used for packing capsule, tablet, softgel, ampoule, vial, injection, liquid, cream, battery etc. in pharmaceutical, medical, food and daily goods etc. industries. Also suitable for small batch production, laboratory, hospital, college etc.. It conforms to GMP, cGMP, CE, TüV etc.
Feature
5) Adopt photoelectric control system and ensure all the stations synchronization and stability.
7)It is small volume and light weight, and one worker could move it easily.
| Max. punch frequency | Alu Pvc: 40 punches/min Alu Alu: 30 punches/min |
| Max. capacity | 2400 blisters/hour ( standard blister 80*57mm) |
| Max. forming area | 120×80mm |
| Adjusted travel | 20-75mm |
| Max. Forming depth | 26mm |
| Specification of packing material | PVC: 120×0.25 (0.15-0.50) mm |
| PTP: 120×0.02(0.02-0.035) mm | |
| Dialysis paper: 120mm× (50-100g) | |
| Diameter of roller: Φ 76mm | |
| Power supply | 220V 50HZ 2.4Kw |
| Mould cooling | Tap water or recycling water 50L/H |
| Air compressor | ≥0.25m3/min |
| Pressure | 0.5-0.8 Mpa |
| Overall dimension | 1996×592×1229 mm |
| Weight | 350Kgs |
It is widely used for packing capsule, tablet, softgel, ampoule, vial, injection, liquid, cream, battery etc. in pharmaceutical, medical, food and daily goods etc. industries. Also suitable for small batch production, laboratory, hospital, college etc.. It conforms to GMP, cGMP, CE, TüV etc.
Feature
5) Adopt photoelectric control system and ensure all the stations synchronization and stability.
7)It is small volume and light weight, and one worker could move it easily.
| Max. punch frequency | Alu Pvc: 40 punches/min Alu Alu: 30 punches/min |
| Max. capacity | 2400 blisters/hour ( standard blister 80*57mm) |
| Max. forming area | 120×80mm |
| Adjusted travel | 20-75mm |
| Max. Forming depth | 26mm |
| Specification of packing material | PVC: 120×0.25 (0.15-0.50) mm |
| PTP: 120×0.02(0.02-0.035) mm | |
| Dialysis paper: 120mm× (50-100g) | |
| Diameter of roller: Φ 76mm | |
| Power supply | 220V 50HZ 2.4Kw |
| Mould cooling | Tap water or recycling water 50L/H |
| Air compressor | ≥0.25m3/min |
| Pressure | 0.5-0.8 Mpa |
| Overall dimension | 1996×592×1229 mm |
| Weight | 350Kgs |
